Calculate the Dial pressure of Hot Press which will be given based on plywood size. Which will be calculated as follows
Calculate the area of the plywood
Assembly Plywood Size- 99 Inch (251 cm ) X 50 Inch (127 cm) =31877 cm2
Dial Pressure Calculator
Dial Pressure = Ply Area (cm) × Specific Pressure (Kg) Ram Area (kg/cm²)
Ply Area = Length × Width
Example:
Dial Pressure = 127 (cm) × 251 (cm) × 11 (Kg) 2512 (kg/cm²)
Dial Pressure = 140 (kg/cm²)
Fill Details & Calculate
15 Daylight – Hot Press Pressure Chart
| Specific Pressure | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Dial Pressure MPa | 12.2 | 13.2 | 14.7 | 15.7 | 17.6 | 18.6 | 19.6 | 21 | 22 | 23.5 | 24.5 | 26 | 27.4 | 28.4 | 29.4 |
| Kg/cm² | 125 | 140 | 150 | 165 | 180 | 190 | 200 | 215 | 230 | 240 | 250 | 265 | 280 | 290 | 300 |
Use the Specific Pressure column from this chart as input in the calculator above to find the required Dial Pressure.
